0.5mm hole drilling

This topic has 7 replies, 5 voices, and was last updated 24 December 2011 at 13:36 by David Littlewood.

Viewing 8 posts - 1 through 8 (of 8 total)

Author

Posts
22 December 2011 at 13:32 #80263
Paul Townsend
Participant
@paultownsend80910
I have a number of 0.5mm holes to drill in silver steel or mild steel and have had trouble with drills jamming and breaking on break through.

Any tips available?
Advert

22 December 2011 at 13:32 #30360
Paul Townsend
Participant
@paultownsend80910
22 December 2011 at 14:30 #80266
David Littlewood
Participant
@davidlittlewood51847
Paul,

See the recent thread Here where it was discussed in detail.

You shouldn’t normally (assuming a perpendicular hole) have too much trouble on break through with steel (worse on brass and other Cu alloys) but if so, put a thin steel backing sheet behind.

David

Edited By David Littlewood on 22/12/2011 14:32:53
22 December 2011 at 22:21 #80287
alan frost
Participant
@alanfrost17805
I would recommend the purchase of the Arc Eurotrade microdrill adaptor mit appropriate chuck. One of the bargains of the century if you look at what these things normally cost even from good value suppliers like J and L. No connection with any of them (or even with reality)-just a happy customer of both..
23 December 2011 at 07:23 #80302
Paul Townsend
Participant
@paultownsend80910
Ta for responses.

The holes are for pinning loco driver wheels to 1/8″ axles in 4mm scale and are at 45degrees.

I have a jig which helps file an angled flat on the axle end (machined off after drilling) so the drill starts perpendicular to the surface, hence progresses easily with my high speed drill press, the axle is clamped in the 45degree jig. The breakthrough is then at 45 degrees in the round surface and that is where breakage is high. I am wondering if some sort of sleeve slipped on the axle while drilling would help. If so what material is recommended?

A friend has recommended using an archimedes drill instead of HS machine.

I will try the Arc adaptor.
23 December 2011 at 09:02 #80303
JasonB
Moderator
@jasonb
Yes I’d make a sleeve or “U” shaped block of the same material to run the drill into so in effect it never breaks out into air or a softer material.

J
24 December 2011 at 13:15 #80388
MICHAEL WILLIAMS
Participant
@michaelwilliams41215
Hi Paul ,

Have a look at the lathe mounted Levin microdrilling system for ideas on this . The general idea is that a very little high speed drill press is fitted with a micrometer depth stop . Instead of setting the depth stop to the finished depth in the normal way you set it just under the drilling spindles current position . The drill works by the user pushing down gently on the operating handle while slowly and evenly lowering the depth stop using its micrometer wheel . Thus rate of feed and depth of cut are entirely controlled by the stop and drilling cannot proceed too fast or overrun . Also at any time the drill may be withdrawn using the operating lever and returned to the exact same depth it was released from . Levin microdrilling system can drill holes down to .004 inch .

If you have a look at Levin site make sure you look at the lathe based drilling system not the delightful but conventional watchmakers drill they also have .

MW
24 December 2011 at 13:36 #80390
David Littlewood
Participant
@davidlittlewood51847
To drill a hole in an angled surface, it can be quite useful to start it with a slot drill. For this use you can get away with using a drill chuck as there is little sideways pressure. This is also useful for starting holes in lost wax brass castings with uneven finishes.

I suppose you could minimise problems on breakout by continuing all the way through, though most times the slot drill would not be long enough.

David

Edited By David Littlewood on 24/12/2011 13:36:58
